Ihagee Exa 1c (1985)

This is an Exa 1c, a 35mm SLR camera sold under the name Ihagee, but manufactured by Certo Camera Werk in Dresden, East Germany, who at the time were both part of VEB Pentacon.  The Exa 1c was produced for less than three years and was the last in the Exa series of SLR cameras, originally built by Ihagee starting in 1950 and the last camera ever to be made bearing the name “Ihagee”.  The Exa 1c does not use the original Exakta bayonet lens mount popularized by the original Kine Exakta camera from the 1930s and instead uses the M42 screw mount.  As with all Exa models, it was aimed at the amateur photographer, featuring a limited shutter and a simplistic feature set.

Film Type: 135 (35mm)
Lens: 50mm f/2.8 Carl Zeiss Jena Tessar coated 4-elements
Lens Mount: M42 Screw Mount
Focus: Variable
Viewfinder: Interchangeable SLR Pentaprism
Shutter: Guillotine-style Behind the Lens
Speeds: B, 1/30 – 1/175 seconds
Exposure Meter: None
Battery: None
Flash Mount: PC M and X Flash Sync
Weight: 662 (w/ lens), 493 grams (body only)
Manual: http://www.ihagee.org/Manuals/ECM108-ExaIcGebrauch86.pdf

How these ratings work
The Exa 1c is the last remnant in the long and successful lineage of the Ihagee Exakta.  Evolved from the original 1950 Exa, the 1c uses the same interchangeable viewfinders, shares a vaguely similar body shape, and retained the left hand shutter release, but not much else.  This is a very basic camera with a limited 5 speed shutter, uses the M42 screw mount, and lacks modern conveniences like an automatic resetting exposure counter or any kind of information in the viewfinder.  It’s saving grace is the “kit” lens that usually came with it, a Zeiss Tessar 50/2.8 lens which like every Tessar that came before it, is capable of really nice images.
Images Handling Features Viewfinder Feel & Beauty History Age
2 1 0 0 1 0 0%
Bonus none
Final Score 4.0



History

Ihagee was founded in 1912 by a Dutchman named Johan Steenbergen as Industrie-und Handelsgesellschaft which stands for Industry and Trade Society.  Often referred to by the nickname IHG, the company name was eventually shortened to Ihagee Kamerawerk since Ihagee is pronounced the same in German as saying “I H G”.  I should point out that contrary to how it appears, there is no “J” in Ihagee.  Many people incorrectly list this company as Jhagee.

In the early years, Ihagee produced a variety of plate and roll film cameras, but it wasn’t until their release of a solid bodied single lens reflex camera called the Exakta where the company began to make a name for itself.  Desgined by Karl Nüchterlein, the original Exakta made it’s debut in 1933 and used 127 roll film.  It was the first single lens reflex camera to use 127 film.

A pair of early VP Exaktas.  Image used with permission, willboy2010, Flickr.

Today, this original camera is unofficially called the VP, or Vest Pocket Exakta to differentiate itself from a later model, also called the Exakta that was designed for 35mm film which made it’s debut in 1936.  Although sharing the same name and same general trapezoidal shape, the Kine Exakta was quite a bit more sophisticated than the VP Exakta.  Featuring an all new bayonet Exakta lens mount and interchangeable viewfinders, the 35mm version earned the nickname of “Kine Exakta” because at the time, 35mm film was still considered by many to be cinema (or kine) film.

The Exakta would go on to become one of the most popular and successful 35mm “system” cameras and a huge number of lenses and other accessories were made for it.  Exaktas were used by amateur and professional photographers, the military, and even in scientific applications.  The Exakta would receive regular updates, tweaking the design and adding new features and would stay in continuous production until 1972, at which time, the Exakta name would be used on an unrelated 35mm SLR designed by (then) parent company VEB Pentacon, called the Exakta 1000 RTL.

This ad from August 1955 shows the huge price difference between the original Exa and an Exakta.

Although tremendously successful, the Exakta wasn’t cheap.  It was a fully featured camera with an advanced shutter, and supported a whole host of high quality lenses and accessories.  For the amateur photographer who wanted the benefits of the Exakta system, but not the high price, in 1950 Ihagee would release a scaled down and less expensive version of the Exakta Varex called the Exa.  The Exa would feature a similar looking body that supported the same bayonet lens mount and interchangeable viewfinders, but offered a much simpler shutter with a top speed of 1/150 and lacked other features such as the cassette to cassette transport system.

The ad to the right from the August 1955 issue of Modern Photography lists an Exakta VX with pentaprism viewfinder and 58mm f/2 Zeiss Biotar lens for $392.  Comparatively, an Exa with waist level finder and 50mm f/2.8 Isco Westanar lens cost $129.50.  Upgrading the Exa with a pentaprism viewfinder brought the price up to $159.50, still less than half that of the Exakta.  When adjusted for inflation, these prices are comparable to $3730, $1230, and $1520 respectively.

Like it’s bigger brother, the original Exa (later renamed the Exa 1a) would receive numerous cosmetic and functional improvements over the years and would remain in production until 1977.  In 1959, an alternate version of the Exa, called the Exa II would be produced concurrently with the original Exa which featured a fixed pentaprism viewfinder, a cloth focal plane shutter with speeds up to 1/250, a film advance lever and a revised body, but otherwise still supported the same lenses as it’s bigger brothers.  The Exa II would later be renamed either Exa 500, Exakta 500, or VX 200 depending on market, and it’s shutter improved to support a top 1/500 shutter speed.  The Exa II/500 series would be discontinued in 1970, around the time of Ihagee’s acquisition by VEB Pentacon.

With the discontinuation of the Exa 1a in 1977, a replacement model produced entirely by VEB Pentacon sharing a similar body but now supporting the M42 screw mount instead of the original Exakta bayonet, was released called the Exa 1b.  The Exa 1b still supported the use of Exakta viewfinders, but with it’s new lens mount, is not considered by most Exakta collectors to be of the original Exakta family.

An Exa 1b, 1c, and VX200 (name variant of Exa 500) are all examples of what Pentacon was doing with the name.  Image courtesy Oldcam87, Flickr.

Over the next several years, the Exa 1b would continue to be cheapened with several pieces of the camera replaced by plastic instead of metal like on the original.  In 1985, production of the Exa would switch from Pentacon’s main Dresden plant to that of another Pentacon company, Certo Camera Werk.  Shortly after production was switched to Certo, the Exa 1b would be renamed the 1c, without any other changes.  Production of the Exa 1c would end in 1987 officially ending the lineage of cameras dating back to the original 127 roll film Exakta from 1933.

Little is known about who the Exa 1c was marketed to.  I found no advertising material, no reviews, and no evidence that it was ever on sale here in the US.  I contacted Hugo Ruys from ihagee.org, one of the most comprehensive sites about all things Ihagee, and he responded that he has absolutely no information about the 1c.  Obviously it did exist, otherwise I wouldn’t have one, but who bought it, or for how much is anyone’s guess.

Edit 7/25/19: I was contacted by Hugo Ruys of ihagee.org, who recently found this German language brochure for the Exa 1c.  It’s not in English, but still offers a glimpse of how this camera was marketed upon it’s release.  Thanks Hugo!

Exa1cBrochure

Today, these later Exas are collectible, only if for their curiosity.  Compared to anything else being made in the mid 1980s when this model was in production, this camera was a relic from a bygone era.  If you can find one cheaply, it’s rudimentary design means it will still likely work fine, and with it’s Zeiss Tessar lens, it’s still capable of good photographs.



The Exa 1c shares it’s basic body shape and left finger shutter release with Exas that came before it, but uses the M42 screw mount.

My Thoughts

What is a camera?  In it’s most basic form, a camera is a light tight box with something, usually a lens, that focuses light onto a specific surface with some type of light sensitive material (film or a digital sensor).  A camera can be as simple as a ‘camera obscura’ or a box camera, all the way to the most state of the art full frame digital mirrorless cameras.

While we often associate the simplest of cameras to also have simple lenses, what happens when you take a very simple camera and put a good lens on it?  If that was a question you’ve ever wondered about, the Exa 1c is your answer.

Produced from 1985 – 1987, the Exa 1c is laughably outdated in every way,  The camera’s shutter dates back to the original Exa from 1950 and has a top speed of 1/175 second, a top speed common with folding Kodaks from the 1930s.  I used to think that 35mm cameras had one of two types of shutter, either a focal plane (cloth or metal) or a leaf shutter.  The Exa has a third, which can only be described as a sort of ‘guillotine’ style, in which there is a curved opening beneath the reflex mirror that opens with a spring loaded flap that closes fractions of a second after the mirror flips up upon releasing the shutter.  The only other camera I’ve ever seen with a shutter like this is the Chinese made Continental TXL that itself was a copy of the Fujica ST-F.  Rather than attempt to explain it in words, here are three images of the shutter in it’s resting (mirror up), cocked (mirror down), and open states.

In the first image, you can see the shutter in it’s resting stage.  The shutter is not cocked, the mirror is up, and the viewfinder is blanked out.  Upon winding the film advance lever, the mirror drops, allowing light to pass through to the viewfinder, and the shutter is cocked.  When the shutter release is pressed, the mirror swings back up, momentarily opening a rectangular window in the curved metal plate beneath it, then depending on the shutter speed set, a door will close behind the mirror, covering up the window.  In the third image above, I have the camera in Bulb mode to keep it open, as normally this window would be open too short of a time for me to capture an image.  It’s a rudimentary system, but does seem to work well, albeit with a very limited selection of speeds.

The viewfinder is bright and easy to compose with, but offers no information about the camera’s settings or exposure.
The Exa uses the same viewfinders as the Exakta, which means the focusing screen is part of the viewfinder, and not the camera body.

The viewfinder is interchangeable, allowing for both a pentaprism or an optional waist level finder.  The ground glass focusing screen is extremely basic, showing no meter, no indication of the settings of the camera, not even any kind of focus aide like a split image rangefinder or microprism circle.  There’s literally nothing other than a large swath of froster glass.  Thankfully, the camera does support automatic M42 lenses, allowing you to compose your images with the lens wide open.  Strangely, the German language manual that came with my Exa 1c shows a focusing screen with a split image focus aide and microprism collar that may have been available for it.  Since Exakta viewfinders contain the focusing screen, it is possible that this camera optionally came with such a viewfinder.

With the release of the Exa 1b, the lens mount changed from the Exakta mount to a M42 screw mount.

Earlier Exas used the original Exakta lens mount which dates back to the 1930s, and fell out of favor with professional photographers in the 1960s.  Replacing it was the venerable M42 mount which itself dates back to the late 1940s, hardly an advancement.  Yet, with a new mount, it allowed access to a huge library of excellent lenses made by companies all over the world.  Schneider and Zeiss lenses from Germany, Asahi Pentax Takumars and Yashica Yashinon lenses from Japan, and even Soviet era Helios lenses were all made using the M42 mount and are compatible with the Exa 1c.

The removable viewfinder dominates the top plate of the camera.

The top plate of the camera is dominated by the pentaprism viewfinder in the middle.  On the left side of the prism is the fold out rewind knob and shutter speed dial.  Strangely, the shutter speed dial has no click stops for each of the 5 indicated speeds plus bulb.  It just smoothly rotates from the fastest 1/175 speed down to B which causes me to have serious concern about the accuracy of each speed.  Notice that there is no top plate shutter release.  Like all Exa and Exaktas that came before it, the Exa 1c’s shutter release is on the front of the camera, near the 2 o’clock position around the lens mount.

On the right side of the prism where you might expect the shutter release is a chrome film rewind button that you must press and hold when you are ready to rewind your film back into the cassette.  When I first got this camera, I had thought that perhaps this was a lock release for the viewfinder, but on mine the viewfinder can be removed with or without this button pressed in, so that couldn’t be it.  Next to the chrome button is the film advance lever with combined manually resetting exposure counter and film reminder dial.

The chrome lever to the left of the eye piece of a shutter release lock.  In the position shown here, the shutter is unlocked.

The back of the camera shows the somewhat large rectangular viewfinder, and to the left a shutter release lock.  With this lever in the down position, a red dot is exposed which prevents the shutter from being fired.  You must move this lever to the position covering the red dot to unlock the shutter release.  The first time I handled this camera, I mistakenly thought the shutter was seized, but it was just locked.

The bottom of the camera has a 1/4″ tripod socket with a metal collar around it which is the film door/back release.

The bottom of the camera is about as bare as it gets, featuring a metal 1/4″ tripod socket with a metal ring around it that functions as the film door release.  There is a red dot on this ring and another on the bottom plate, with these two dots lined up, the entire back and bottom of the camera comes off in one piece.  To lock the door, rotate this ring 90 degrees so the dot is facing the rear of the camera.

Like earlier Exas, the entire back and bottom come off for film loading.

The film compartment is one of the few areas in which Certo’s attempts to cheapen the camera are less obvious.  There are metal rollers and a double geared feeler shaft, along with polished metal film rails, and all metal cassette forks.  This might seem like me grasping at nice things to say about the camera, but I’ve seen worse.  Film transport is from left to right onto a removable plastic take up spool.  The spool is notched in two places, somewhat simplifying film loading.

This Exa 1c came to me with the original German language owner’s manual.

So back to my original question of what happens when you mount a quality lens to a basic camera, this is your answer.  The Exa 1c is about as basic of a camera as you can get.  It’s rudimentary shutter and featureless viewfinder is outclassed by nearly every camera made since the mid 20th century.  Yet, like a box camera, when you work within it’s strengths is capable of some really nice images.

I doubt anyone reading this article would buy into me calling the Exa 1c a box camera, so maybe I should call it an Single Lens Reflex Light Box…a SLRLB!  Hmm, maybe I should copyright that!



My Results

I have to admit, I was both dreading and looking forward to using the Exa 1c.  I figured that the reputation of the Zeiss Tessar lens should produce some pretty decent looking shots, but the rudimentary feature set of the camera might make it a chore to use.  Not wanting to keep this camera sitting idle too long, I loaded up a semi-expired bulk roll of Kodak Plus-X 125.  I had shot this film before and knew it was still usable at box speed so I figured the film’s 125 speed would be an ideal match for the Exa’s limited shutter speeds.

The images from the Exa are as good as you might expect from any camera with an M42 Tessar and for that, I’d say it performed well.  In fact, with the screw mount Tessar attached, the camera likely has more value, simply for the lens which can be used on any other M42 screw mount film camera, or even adapted to digital.

The Exa 1c may be a cheap camera, but the Zeiss Tessar delivers nice and sharp results.

Frankly, that’s the best thing I can say about it though.  I fully understand the need for simple, all mechanical cameras that leave 100% of the photo making decisions up to the photographer, but for a camera that made it’s debut in 1985 when even the simplest of point and shoot cameras could create photographs equally as good, and with less effort, I have to ask why this camera exists at all.

Who was it’s intended customer?  Why would anyone choose a camera with a feature set that matched cameras from 20-30 years prior?  Perhaps, I just don’t understand the economy of Cold War era East Germany in the 1980s.  Looking back from a historical perspective, this camera’s mere existence makes no sense.  With a large number of mechanical Prakticas that used the same lens mount, and with more capable shutters and viewfinders, I simply don’t understand why anyone would buy it.

But they did.  It’s certainly not a common model, but it was easy enough for me to find cheap, and a quick look at eBay returns at least 10 more, so some had to have been sold and I guess when you look at it purely from a functional perspective, it does work, and as the gallery above shows, it made nice photos.
